widget_recorder_plus #

A powerful Flutter package to record any widget as MP4 video, animated GIF, or high-quality screenshot. Features touch visualization for tutorials, automatic permission handling, and simple API. Perfect for creating demos, tutorials, and documentation.

Demo #

Widget Recorder Demo

✨ Features #

🎥 Video Recording #

MP4 Video Export - High-quality H.264 video codec with optimized bitrate
Audio Recording - Optional microphone audio capture (iOS & Android)
Automatic Permissions - Built-in permission handling with customizable dialogs
Video Quality Presets - Low (15 FPS, 2 Mbps), Medium (30 FPS, 5 Mbps), High (60 FPS, 10 Mbps) (NEW v1.0.5)
Countdown Timer - 3-2-1 countdown before recording starts (NEW v1.0.5)
Custom Save Path - Save to custom directories (NEW v1.0.5)
Configurable FPS - 15-60 FPS (default 60)
Proper Finalization - Ensures video files are always valid

📸 Screenshot Capture (NEW v1.0.5) #

High-Quality Screenshots - PNG/JPG export with configurable resolution
Retina Support - Adjustable pixel ratio for ultra-high-res captures
Instant Capture - Single-frame screenshot with one method call

🎞️ GIF Export (NEW v1.0.5) #

Animated GIFs - Export widgets as shareable GIF files
Quality Presets - Low, Medium, High (10-24 FPS, 64-256 colors)
Auto or Manual - Timed recording or manual start/stop control
Optimized Encoding - Color quantization for smaller file sizes

👆 Touch Visualization (NEW v1.0.5) #

Touch Indicators - Show touch points during recording
Ripple Effects - Animated ripples on tap with customizable colors
Fully Customizable - Size, color, opacity, and animation duration
Tutorial Perfect - Ideal for app demonstrations and user guides

🛠️ General Features #

Simple API - Just 3 lines to integrate
Cross-Platform - Android (API 21+) and iOS (13+)
Auto File Management - No path management needed
Built-in Callbacks - Success and error handling
Smooth Encoding - Optimized for performance

Platform Support #

Platform	Min Version	Status
Android	API 21 (5.0)	✅ Fully Supported
iOS	13.0	✅ Fully Supported
Web	-	❌ Not Supported
macOS	-	❌ Not Supported
Windows	-	❌ Not Supported
Linux	-	❌ Not Supported

Installation #

Add to your pubspec.yaml:

dependencies:
  widget_recorder_plus: ^1.0.5

Then run:

flutter pub get

Quick Start #

Video Recording #

1. Import the Package #

import 'package:widget_recorder_plus/widget_recorder_plus.dart';

2. Create a Controller #

final controller = WidgetRecorderController(
  recordAudio: true, // Enable audio recording (permission handled automatically!)
  customSavePath: '/path/to/save/directory', // Optional: custom save location
  onComplete: (path) => print('Video saved: $path'),
  onError: (error) => print('Error: $error'),
);

3. Wrap Your Widget #

WidgetRecorder(
  controller: controller,
  child: YourWidget(),
)

4. Start Recording #

Basic:

// Start recording immediately
await controller.start();

// Stop recording (returns file path)
final videoPath = await controller.stop();

With Countdown (NEW v1.0.5):

// Start with 3-second countdown
await controller.startWithCountdown(
  countdownSeconds: 3,
  onTick: (remaining) => print('Starting in $remaining...'),
);

With Quality Preset (NEW v1.0.5):

// Apply quality preset before recording
controller.applyVideoQuality(VideoQuality.high); // 60 FPS, 10 Mbps
await controller.start();

🎯 Video Quality Presets (NEW v1.0.5) #

Choose from predefined quality presets for optimal balance between file size and quality:

final controller = WidgetRecorderController();

// Apply quality preset
controller.applyVideoQuality(VideoQuality.low);    // 15 FPS, 2 Mbps
controller.applyVideoQuality(VideoQuality.medium); // 30 FPS, 5 Mbps (recommended)
controller.applyVideoQuality(VideoQuality.high);   // 60 FPS, 10 Mbps

// Then start recording
await controller.start();

Video Quality Comparison #

Preset	FPS	Bitrate	File Size*	Use Case
`VideoQuality.low`	15	2 Mbps	~15 MB/min	Quick sharing, small file size
`VideoQuality.medium`	30	5 Mbps	~38 MB/min	Balanced quality & size
`VideoQuality.high`	60	10 Mbps	~75 MB/min	Best quality, smooth motion

*Approximate file sizes for 720p resolution

⏱️ Countdown Timer (NEW v1.0.5) #

Give yourself time to prepare before recording starts:

Basic Countdown #

// Start with 3-second countdown
await controller.startWithCountdown(
  countdownSeconds: 3,
  onTick: (remaining) {
    print('Starting in $remaining...');
  },
);

Custom Countdown UI #

int countdownValue = 0;

await controller.startWithCountdown(
  countdownSeconds: 5,
  onTick: (remaining) {
    setState(() {
      countdownValue = remaining;
    });
  },
);

// Display countdownValue in your UI
Text('Recording in: $countdownValue', style: TextStyle(fontSize: 48));

Use Cases #

Hands-free recording - Get ready without rushing
Self-recording - Position yourself before capture starts
Professional videos - Smooth start without fumbling
Live demos - Time to prepare your demonstration

📁 Custom Save Path (NEW v1.0.5) #

Save recordings to custom locations instead of temp directory:

// Save to documents directory
final controller = WidgetRecorderController(
  customSavePath: '/path/to/your/directory',
);

// Or use path_provider for platform directories
import 'package:path_provider/path_provider.dart';

final appDocDir = await getApplicationDocumentsDirectory();
final controller = WidgetRecorderController(
  customSavePath: '${appDocDir.path}/my_recordings',
);

// All recordings (video, screenshot, GIF) will save to custom path
await controller.start();
await controller.captureScreenshot();
await controller.exportAsGif();

Benefits #

Organized storage - Keep recordings in dedicated folders
Easy access - Find files quickly
Gallery integration - Save to photo library directory
App-specific storage - Isolate from system temp files

📸 Screenshot Capture #

Capture high-quality screenshots of any widget instantly:

// Create controller
final controller = WidgetRecorderController();

// Wrap your widget
WidgetRecorder(
  controller: controller,
  child: MyWidget(),
)

// Capture screenshot (PNG format, 3x retina resolution)
final screenshotPath = await controller.captureScreenshot(
  format: ImageFormat.png,
  pixelRatio: 3.0,
);

print('Screenshot saved: $screenshotPath');

Screenshot Options #

await controller.captureScreenshot(
  format: ImageFormat.png,  // ImageFormat.png or ImageFormat.jpg
  pixelRatio: 3.0,          // 1.0 = normal, 2.0 = retina, 3.0 = ultra-high-res
  quality: 100,             // 1-100 (for JPG only, ignored for PNG)
);

🎞️ GIF Export #

Export widgets as animated GIFs - perfect for documentation and sharing:

Automatic Timed Recording #

final controller = WidgetRecorderController();

// Record for 3 seconds and export as GIF
final gifPath = await controller.exportAsGif(
  duration: Duration(seconds: 3),
  quality: GifQuality.medium,
);

print('GIF saved: $gifPath');

Manual Control #

// Start GIF recording
await controller.startGifRecording(quality: GifQuality.high);

// ... user interacts with widget ...

// Stop and export
final gifPath = await controller.stopGifRecording(quality: GifQuality.high);

GIF Quality Presets #

Preset	FPS	Colors	File Size	Use Case
`GifQuality.low`	10	64	Smallest	Quick demos, small file sharing
`GifQuality.medium`	15	128	Balanced	General purpose, documentation
`GifQuality.high`	24	256	Largest	Smooth animations, high quality

// Example with different qualities
await controller.exportAsGif(
  duration: Duration(seconds: 5),
  quality: GifQuality.high,  // Best quality
);

👆 Touch Visualization #

Show touch indicators during recording - perfect for tutorials and app demos:

Basic Usage #

final controller = WidgetRecorderController(
  showTouches: true,  // Enable touch visualization
  touchConfig: TouchVisualizationConfig(
    color: Colors.blue,
    size: 50,
    opacity: 0.6,
    showRipple: true,
  ),
);

Full Configuration #

final controller = WidgetRecorderController(
  showTouches: true,
  touchConfig: TouchVisualizationConfig(
    color: Colors.blue,                           // Touch indicator color
    size: 50.0,                                   // Indicator size in pixels
    opacity: 0.6,                                 // 0.0 to 1.0
    showRipple: true,                             // Animated ripple effect
    rippleDuration: Duration(milliseconds: 300),  // Ripple animation duration
  ),
);

Use Cases #

App Tutorials - Show users where to tap
Feature Demos - Highlight interactive elements
Bug Reports - Show exact tap locations
Marketing Videos - Professional-looking demonstrations

Complete Example #

import 'package:flutter/material.dart';
import 'package:widget_recorder_plus/widget_recorder_plus.dart';
import 'package:open_file/open_file.dart';

void main() => runApp(const MyApp());

class MyApp extends StatefulWidget {
  const MyApp({Key? key}) : super(key: key);

  @override
  State<MyApp> createState() => _MyAppState();
}

class _MyAppState extends State<MyApp> {
  late WidgetRecorderController controller;
  bool isRecording = false;

  @override
  void initState() {
    super.initState();
    controller = WidgetRecorderController(
      showTouches: true,  // NEW: Enable touch visualization
      onComplete: (path) {
        setState(() => isRecording = false);
        ScaffoldMessenger.of(context).showSnackBar(
          SnackBar(
            content: Text('Saved: $path'),
            action: SnackBarAction(
              label: 'Open',
              onPressed: () => OpenFile.open(path),
            ),
          ),
        );
      },
      onError: (error) {
        setState(() => isRecording = false);
        ScaffoldMessenger.of(context).showSnackBar(
          SnackBar(content: Text('Error: $error'), backgroundColor: Colors.red),
        );
      },
    );
  }

  @override
  void dispose() {
    controller.dispose();
    super.dispose();
  }

  Future<void> toggleRecording() async {
    if (isRecording) {
      await controller.stop();
    } else {
      setState(() => isRecording = true);
      await controller.start();
    }
  }

  // NEW: Capture screenshot
  Future<void> captureScreenshot() async {
    final path = await controller.captureScreenshot();
    print('Screenshot: $path');
  }

  // NEW: Export GIF
  Future<void> exportGif() async {
    await controller.exportAsGif(
      duration: Duration(seconds: 3),
      quality: GifQuality.medium,
    );
  }  }

  @override
  Widget build(BuildContext context) {
    return MaterialApp(
      home: Scaffold(
        appBar: AppBar(title: const Text('Widget Recorder Demo')),
        body: Center(
          child: Column(
            mainAxisAlignment: MainAxisAlignment.center,
            children: [
              WidgetRecorder(
                controller: controller,
                child: Container(
                  width: 300,
                  height: 300,
                  decoration: BoxDecoration(
                    gradient: LinearGradient(
                      colors: [Colors.blue, Colors.purple],
                    ),
                    borderRadius: BorderRadius.circular(20),
                  ),
                  child: const Center(
                    child: Text(
                      'Recording this!',
                      style: TextStyle(
                        color: Colors.white,
                        fontSize: 24,
                        fontWeight: FontWeight.bold,
                      ),
                    ),
                  ),
                ),
              ),
              const SizedBox(height: 40),
              ElevatedButton.icon(
                onPressed: toggleRecording,
                icon: Icon(isRecording ? Icons.stop : Icons.videocam),
                label: Text(isRecording ? 'Stop Recording' : 'Start Recording'),
              ),
            ],
          ),
        ),
      ),
    );
  }
}

API Reference #

WidgetRecorderController #

Main controller for managing widget recording, screenshot capture, and GIF export.

Constructor

WidgetRecorderController({
  Function(String path)? onComplete,
  Function(String error)? onError,
  bool recordAudio = false,
  Widget Function(BuildContext context, VoidCallback openSettings)? permissionDeniedDialog,
  bool showTouches = false,  // NEW v1.0.5
  TouchVisualizationConfig touchConfig = const TouchVisualizationConfig(),  // NEW v1.0.5
  String? customSavePath,  // NEW v1.0.5
})

Parameters:

onComplete - Called when recording/export finishes with the file path
onError - Called when an error occurs
recordAudio - Enable microphone audio recording (default: false)
permissionDeniedDialog - Optional custom dialog when permission is denied
showTouches - Enable touch visualization (default: false) NEW v1.0.5
touchConfig - Touch indicator configuration NEW v1.0.5
customSavePath - Custom directory for saving files (optional) NEW v1.0.5

Properties

// Set frames per second for video recording (15-60, default: 60)
controller.fps = 30;

// Apply video quality preset (NEW v1.0.5)
controller.applyVideoQuality(VideoQuality.medium);

// Check if currently recording video or GIF
bool isRecording = controller.isRecording;

// Check if currently recording GIF specifically
bool isRecordingGif = controller.isRecordingGif;  // NEW v1.0.5

Video Recording Methods

// Start video recording (auto-generates file path)
await controller.start();

// Start with countdown (NEW v1.0.5)
await controller.startWithCountdown(
  countdownSeconds: 3,
  onTick: (remaining) => print('Starting in $remaining'),
);

// Start with custom countdown duration (NEW v1.0.5)
await controller.start(
  countdown: Duration(seconds: 5),
  onTick: (remaining) => print('$remaining'),
);

// Stop video recording (returns file path)
final path = await controller.stop();

Screenshot Methods (NEW v1.0.5)

// Capture high-quality screenshot
final screenshotPath = await controller.captureScreenshot(
  format: ImageFormat.png,  // ImageFormat.png or ImageFormat.jpg
  quality: 100,             // 1-100 (for JPG only)
  pixelRatio: 3.0,          // Resolution multiplier (1.0 = normal, 3.0 = retina)
);

GIF Export Methods (NEW v1.0.5)

// Automatic timed GIF recording
final gifPath = await controller.exportAsGif(
  duration: Duration(seconds: 3),
  quality: GifQuality.medium,
);

// Manual GIF recording (start)
await controller.startGifRecording(
  quality: GifQuality.medium,
);

// Manual GIF recording (stop and export)
final gifPath = await controller.stopGifRecording(
  quality: GifQuality.medium,
);

Permission Methods

// Manual permission control (optional - not needed with automatic handling)
bool hasPermission = await controller.hasPermission();
bool granted = await controller.requestPermission();
await controller.openSettings();

Cleanup

// Clean up resources
controller.dispose();

WidgetRecorder Widget #

Wrapper widget that enables recording for its child.

WidgetRecorder(
  controller: controller,  // Required
  child: MyWidget(),       // Required
)

TouchVisualizationConfig (NEW v1.0.5) #

Configuration for touch visualization during recording.

const TouchVisualizationConfig({
  Color color = Colors.blue,
  double size = 50.0,
  double opacity = 0.6,
  bool showRipple = true,
  Duration rippleDuration = const Duration(milliseconds: 300),
})

Parameters:

color - Touch indicator color
size - Touch indicator size in pixels
opacity - Touch indicator opacity (0.0 to 1.0)
showRipple - Enable ripple animation effect
rippleDuration - Duration of ripple animation

ImageFormat Enum (NEW v1.0.5) #

enum ImageFormat {
  png,  // PNG format (lossless, larger file size)
  jpg,  // JPG format (lossy, smaller file size)
}

VideoQuality Enum (NEW v1.0.5) #

enum VideoQuality {
  low,     // 15 FPS, 2 Mbps
  medium,  // 30 FPS, 5 Mbps (recommended)
  high,    // 60 FPS, 10 Mbps
}

Properties:

VideoQuality.medium.fps         // 30
VideoQuality.medium.bitrate     // 5000000
VideoQuality.medium.description // "Medium (30 FPS, 5 Mbps) - Balanced"

enum GifQuality {
  low,     // 10 FPS, 64 colors
  medium,  // 15 FPS, 128 colors (recommended)
  high,    // 24 FPS, 256 colors
}

Properties:

GifQuality.medium.fps      // 15
GifQuality.medium.colors   // 128

Usage Examples #

Screenshot for App Store #

class AppStoreScreenshots extends StatelessWidget {
  final controller = WidgetRecorderController();

  Future<void> captureForAppStore() async {
    // Ultra-high resolution for App Store
    final path = await controller.captureScreenshot(
      format: ImageFormat.png,
      pixelRatio: 3.0,  // Retina display quality
    );
    // Upload to App Store Connect
  }

  @override
  Widget build(BuildContext context) {
    return WidgetRecorder(
      controller: controller,
      child: MyAppScreenContent(),
    );
  }
}

GIF for Documentation #

class DocumentationGifs extends StatelessWidget {
  final controller = WidgetRecorderController();

  Future<void> createDocGif() async {
    // Medium quality for README files
    await controller.exportAsGif(
      duration: Duration(seconds: 5),
      quality: GifQuality.medium,
    );
    // Add to repository
  }

  @override
  Widget build(BuildContext context) {
    return WidgetRecorder(
      controller: controller,
      child: AnimatedFeatureDemo(),
    );
  }
}

Tutorial Video with Touch Indicators #

class TutorialRecorder extends StatefulWidget {
  @override
  State<TutorialRecorder> createState() => _TutorialRecorderState();
}

class _TutorialRecorderState extends State<TutorialRecorder> {
  late WidgetRecorderController controller;

  @override
  void initState() {
    super.initState();
    controller = WidgetRecorderController(
      recordAudio: true,  // Record voice narration
      showTouches: true,  // Show where user taps
      touchConfig: TouchVisualizationConfig(
        color: Colors.blue,
        size: 60,
        opacity: 0.7,
        showRipple: true,
      ),
    );
  }

  Future<void> recordTutorial() async {
    await controller.start();
    // User demonstrates the feature
    await Future.delayed(Duration(seconds: 10));
    await controller.stop();
  }

  @override
  Widget build(BuildContext context) {
    return WidgetRecorder(
      controller: controller,
      child: AppInterface(),
    );
  }
}

Automatic Permission Handling #

When recordAudio: true, permissions are handled automatically - no manual checks needed!

final controller = WidgetRecorderController(
  recordAudio: true, // Permission handled automatically
  onComplete: (path) => print('Saved: $path'),
  onError: (error) => print('Error: $error'),
);

// Just call start - permission dialog shows automatically if needed
await controller.start();

Custom Permission Dialog (Optional):

final controller = WidgetRecorderController(
  recordAudio: true,
  permissionDeniedDialog: (context, openSettings) {
    return AlertDialog(
      title: const Text('Microphone Access Required'),
      content: const Text('Please enable microphone in Settings.'),
      actions: [
        TextButton(
          onPressed: () => Navigator.pop(context, false),
          child: const Text('Cancel'),
        ),
        ElevatedButton(
          onPressed: () {
            openSettings(); // Opens app settings
            Navigator.pop(context, true);
          },
          child: const Text('Open Settings'),
        ),
      ],
    );
  },
);

Recording with Audio #

class AudioRecordingDemo extends StatefulWidget {
  @override
  State<AudioRecordingDemo> createState() => _AudioRecordingDemoState();
}

class _AudioRecordingDemoState extends State<AudioRecordingDemo> {
  late WidgetRecorderController controller;

  @override
  void initState() {
    super.initState();
    controller = WidgetRecorderController(
      recordAudio: true, // Enable audio recording (permission handled automatically!)
      onComplete: (path) {
        print('Video with audio saved: $path');
      },
    );
  }

  Future<void> startRecordingWithAudio() async {
    // Just call start - permission is handled automatically!
    await controller.start();
  }

  @override
  Widget build(BuildContext context) {
    return WidgetRecorder(
      controller: controller,
      child: YourWidget(),
    );
  }

  @override
  void dispose() {
    controller.dispose();
    super.dispose();
  }
}

Recording Animations #

class AnimatedDemo extends StatefulWidget {
  @override
  State<AnimatedDemo> createState() => _AnimatedDemoState();
}

class _AnimatedDemoState extends State<AnimatedDemo>
    with SingleTickerProviderStateMixin {
  late AnimationController animController;
  late WidgetRecorderController recController;

  @override
  void initState() {
    super.initState();
    recController = WidgetRecorderController();
    animController = AnimationController(
      duration: const Duration(seconds: 2),
      vsync: this,
    );
  }

  Future<void> recordAnimation() async {
    await recController.start();
    await animController.forward();
    await recController.stop();
  }

  // NEW: Export animation as GIF
  Future<void> exportAnimationAsGif() async {
    await recController.exportAsGif(
      duration: Duration(seconds: 2),
      quality: GifQuality.high,
    );
  }

  @override
  Widget build(BuildContext context) {
    return WidgetRecorder(
      controller: recController,
      child: AnimatedBuilder(
        animation: animController,
        builder: (context, child) {
          return Transform.scale(
            scale: 0.5 + (animController.value * 0.5),
            child: Container(
              width: 200,
              height: 200,
              decoration: BoxDecoration(
                color: Colors.red,
                borderRadius: BorderRadius.circular(20),
              ),
            ),
          );
        },
      ),
    );
  }

  @override
  void dispose() {
    animController.dispose();
    recController.dispose();
    super.dispose();
  }
}

Adjusting Video Quality #

// Lower FPS for smaller files (good for sharing)
controller.fps = 15;

// Medium quality (balanced)
controller.fps = 30;

// High quality (smooth animations)
controller.fps = 60;

Record for Specific Duration #

Future<void> recordForSeconds(int seconds) async {
  await controller.start();
  await Future.delayed(Duration(seconds: seconds));
  await controller.stop();
}

Toggle Recording #

Future<void> toggleRecording() async {
  if (controller.isRecording) {
    await controller.stop();
  } else {
    await controller.start();
  }
}

Permissions #

Android #

Add to android/app/src/main/AndroidManifest.xml (only if saving to external storage):

<uses-permission android:name="android.permission.WRITE_EXTERNAL_STORAGE"
    android:maxSdkVersion="32" />

Note: By default, videos are saved to app-specific directories (no permission needed).

iOS #

Add to ios/Runner/Info.plist (only if saving to Photos library):

<key>NSPhotoLibraryAddUsageDescription</key>
<string>We need access to save recorded videos</string>

Note: By default, videos are saved to app-specific directories (no permission needed).

Performance Tips #

Tip	Benefit
Use FPS 15-24	Smaller files, less CPU usage
Keep widget size <= 1080p	Better performance
Close background apps	More resources available
Test on real devices	Accurate performance metrics
Dispose controller	Prevents memory leaks

Troubleshooting #

Empty or corrupted video file #

Solution: Always call controller.stop() to properly finalize the video. The file is only valid after stop completes.

Widget not captured #

Solution: Ensure the widget is visible on screen during recording. The widget must be rendered to be captured.

Recording is laggy or drops frames #

Solution: Reduce FPS: controller.fps = 15 or reduce widget complexity.

"Unsupported media" error when opening video #

Solution: Ensure recording completed successfully. Wait for onComplete callback before accessing the file.

Permission denied error #

Solution: Check AndroidManifest.xml and Info.plist configurations. Ensure app has necessary permissions.

Build fails on Android #

Solution: Ensure Kotlin support is enabled. Update Android Gradle plugin to 7.0+.

Build fails on iOS #

Solution: Ensure Swift support is enabled. Update iOS deployment target to 13.0+.

Limitations #

Audio capture is supported for video recording only (not for GIF export)
Widget must be visible on screen during recording
Platform views (WebView, MapView) may not capture correctly
Not suitable for real-time streaming
Maximum recommended widget size: 1920x1080
GIF file sizes can be large for long recordings at high quality

How It Works #

Dart Layer - Uses RepaintBoundary to capture widget frames as RGBA pixel data
Frame Conversion - Converts RGBA to YUV420 (Android) or BGRA (iOS)
Native Encoding - Uses MediaCodec (Android) or AVAssetWriter (iOS) for H.264 encoding
MP4 Output - Creates valid MP4 video file with proper timestamps and finalization

Output Specifications #

Video (MP4) #

Property	Value
Format	MP4 (MPEG-4)
Codec	H.264 (AVC)
Container	MP4
Bitrate	10 Mbps per megapixel
FPS	Configurable (15-60, default 60)
Audio	AAC (optional, 128kbps stereo)
Color Space	YUV420 (Android), BGRA (iOS)

Screenshot (NEW v1.0.5) #

Property	Value
Format	PNG (lossless) or JPG (lossy)
Resolution	Configurable via pixelRatio
Default Quality	3x device resolution (retina)
Color Depth	32-bit RGBA
Compression	PNG: lossless, JPG: configurable 1-100

GIF (NEW v1.0.5) #

Preset	FPS	Colors	Typical Size	Best For
Low	10	64	~500KB/sec	Quick sharing, small demos
Medium	15	128	~1MB/sec	Documentation, README files
High	24	256	~2MB/sec	Smooth animations, presentations

File sizes are approximate and vary based on content complexity

App Store Compliance #

Google Play Store - Compliant (in-app widget recording, not screen capture)
Apple App Store - Compliant (internal rendering, not screen recording)

Always include appropriate privacy policy disclosures about video recording features in your app.

Contributing #

Contributions are welcome! Please feel free to submit a Pull Request.

License #

This project is licensed under the MIT License - see the LICENSE file for details.

Support #

Check the example app for working code
Report issues on GitHub
Discuss on pub.dev

Changelog #

Version 1.0.5 (Latest) #

New Features:

✨ Screenshot Capture - Capture high-quality PNG/JPG screenshots with configurable resolution
🎞️ GIF Export - Export widgets as animated GIFs with quality presets (low/medium/high)
👆 Touch Visualization - Show touch indicators during recording with customizable appearance and ripple effects
📐 Configurable Quality - GIF quality presets with FPS and color control

Improvements:

Enhanced API with new methods: captureScreenshot(), exportAsGif(), startGifRecording(), stopGifRecording()
Added TouchVisualizationConfig for customizing touch indicators
Added ImageFormat and GifQuality enums for better type safety
Improved example app with dedicated demo page for new features

Dependencies:

Added image package (^4.1.7) for GIF encoding

Version 1.0.4 #

Features:

MP4 video recording with H.264 codec
Audio recording support (iOS & Android)
Automatic permission handling
Configurable FPS (15-60)
High-quality video encoding
Built-in error handling and callbacks

Contributing #

Contributions are welcome! Please feel free to submit a Pull Request.

License #

This project is licensed under the MIT License - see the LICENSE file for details.

widget_recorder_plus 1.0.5 widget_recorder_plus: ^1.0.5 copied to clipboard

Metadata

widget_recorder_plus #

Demo #

✨ Features #

🎥 Video Recording #

📸 Screenshot Capture (NEW v1.0.5) #

🎞️ GIF Export (NEW v1.0.5) #

👆 Touch Visualization (NEW v1.0.5) #

🛠️ General Features #

Platform Support #

Installation #

Quick Start #

Video Recording #

1. Import the Package #

2. Create a Controller #

3. Wrap Your Widget #

4. Start Recording #

🎯 Video Quality Presets (NEW v1.0.5) #

Video Quality Comparison #

⏱️ Countdown Timer (NEW v1.0.5) #

Basic Countdown #

Custom Countdown UI #

Use Cases #

📁 Custom Save Path (NEW v1.0.5) #

Benefits #

📸 Screenshot Capture #

Screenshot Options #

🎞️ GIF Export #

Automatic Timed Recording #

Manual Control #

GIF Quality Presets #

👆 Touch Visualization #

Basic Usage #

Full Configuration #

Use Cases #

Complete Example #

API Reference #

WidgetRecorderController #

Constructor

Properties

Video Recording Methods

Screenshot Methods (NEW v1.0.5)

GIF Export Methods (NEW v1.0.5)

Permission Methods

Cleanup

WidgetRecorder Widget #

TouchVisualizationConfig (NEW v1.0.5) #

ImageFormat Enum (NEW v1.0.5) #

VideoQuality Enum (NEW v1.0.5) #

Usage Examples #

Screenshot for App Store #

GIF for Documentation #

Tutorial Video with Touch Indicators #

Automatic Permission Handling #

Recording with Audio #

Recording Animations #

Adjusting Video Quality #

Record for Specific Duration #

Toggle Recording #

Permissions #

Android #

iOS #

Performance Tips #

Troubleshooting #

Empty or corrupted video file #

Widget not captured #

Recording is laggy or drops frames #

"Unsupported media" error when opening video #

Permission denied error #

Build fails on Android #

Build fails on iOS #

Limitations #

How It Works #

Output Specifications #

Video (MP4) #

Screenshot (NEW v1.0.5) #

GIF (NEW v1.0.5) #

App Store Compliance #

Contributing #

widget_recorder_plus 1.0.5
widget_recorder_plus: ^1.0.5 copied to clipboard
