pin_plus_keyboard #

A highly customizable Flutter package that provides custom input fields and a custom numeric keyboard for PIN entry, OTP (One-Time Password) widgets, transaction PIN widgets, and simple login widgets.

Features #

✨ Highly Customizable

Customizable input field shapes (circular, rounded, or default)
Customizable keyboard button shapes and styles
Full control over colors, sizes, borders, and shadows
Support for hidden input (password-style)
Custom fonts and text styles
Gradient support for buttons and inputs
Custom builders for complete control
Theme presets (iOS-style, Android-style, Material 3)

🎨 Beautiful UI

Modern and clean design
Smooth animations (fill, shake, success)
Responsive layout
Support for elevation and shadows
Multiple input styles (box or dash)
Material 3 design support
Dynamic color theming

♿ Accessibility

Full screen reader support
Keyboard navigation
Semantic labels and hints
High contrast mode support
ARIA-like attributes

🔒 Security

Auto-clear after inactivity timeout
Screenshot blocking (Android)
Rate limiting for failed attempts
Secure input handling
Random keyboard layout (shoulder surfing protection)

🔐 Biometric Integration

Face ID / Touch ID / Fingerprint support
Optional biometric authentication button
Fallback to PIN when biometrics fail
Platform-agnostic interface

⚡ Easy to Use

Simple API
Well-documented
Comprehensive examples
Type-safe with null safety
Platform-specific optimizations

Getting Started #

Installation #

Add this package to your pubspec.yaml file:

dependencies:
  flutter:
    sdk: flutter
  pin_plus_keyboard: ^3.0.0

For biometric features, also add local_auth:

dependencies:
  local_auth: ^2.0.0  # Optional, for biometric authentication

Then run:

flutter pub get

Import #

import 'package:pin_plus_keyboard/pin_plus_keyboard.dart';

Usage #

Basic Example #

The most basic usage requires three things:

A PinInputController with the desired PIN length
A spacing value for layout
An onSubmit callback function

import 'package:flutter/material.dart';
import 'package:pin_plus_keyboard/pin_plus_keyboard.dart';

class PinEntryScreen extends StatefulWidget {
  const PinEntryScreen({super.key});

  @override
  State<PinEntryScreen> createState() => _PinEntryScreenState();
}

class _PinEntryScreenState extends State<PinEntryScreen> {
  // Initialize the controller with the desired PIN length
  final PinInputController _pinController = PinInputController(length: 6);

  @override
  void dispose() {
    // Don't forget to dispose the controller
    _pinController.dispose();
    super.dispose();
  }

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      body: Center(
        child: Column(
          mainAxisAlignment: MainAxisAlignment.center,
          children: [
            const Text(
              'Enter Your PIN',
              style: TextStyle(fontSize: 24, fontWeight: FontWeight.bold),
            ),
            const SizedBox(height: 40),
            PinPlusKeyBoardPackage(
              pinInputController: _pinController,
              spacing: 40,
              onSubmit: () {
                // This is called when all fields are filled or done button is pressed
                print('PIN entered: ${_pinController.text}');
                // Add your validation/submission logic here
              },
            ),
          ],
        ),
      ),
    );
  }
}

Advanced Example with Customization #

PinPlusKeyBoardPackage(
  // Required parameters
  pinInputController: _pinController,
  spacing: 40,
  onSubmit: () {
    print('PIN: ${_pinController.text}');
  },

  // Input field customization
  inputShape: InputShape.circular,
  inputType: InputType.box,
  inputFillColor: Colors.grey[200],
  inputBorderColor: Colors.blue,
  inputTextColor: Colors.black,
  inputHasBorder: true,
  inputBorderThickness: 2,
  inputElevation: 5,
  isInputHidden: false, // Set to true for password-style input

  // Keyboard customization
  keyboardButtonShape: KeyboardButtonShape.circular,
  buttonFillColor: Colors.blue,
  btnTextColor: Colors.white,
  btnHasBorder: false,
  btnElevation: 3,
  keyboardMaxWidth: 80, // Percentage of screen width

  // Error handling
  errorColor: Colors.red,
)

Example with Material 3 #

PinPlusKeyBoardPackage(
  pinInputController: _pinController,
  spacing: 40,
  onSubmit: () {
    // Handle PIN submission
  },
  // Enable Material 3 design tokens
  useMaterial3: true,
  // Colors will be automatically derived from theme
)

Example with Animations #

PinPlusKeyBoardPackage(
  pinInputController: _pinController,
  spacing: 40,
  onSubmit: () {
    // Handle PIN submission
  },
  // Enable all animations
  enableAnimations: true,
  enableShakeAnimation: true,
  enableSuccessAnimation: true,
  animationCurve: Curves.easeInOut,
  animationDuration: Duration(milliseconds: 300),
)

Example with Biometric Authentication #

PinPlusKeyBoardPackage(
  pinInputController: _pinController,
  spacing: 40,
  onSubmit: () {
    // Handle PIN submission
  },
  // Enable biometric authentication
  enableBiometric: true,
  biometricReason: 'Please authenticate to access your account',
  onBiometricSuccess: () {
    print('Biometric authentication successful');
  },
  onBiometricFailure: () {
    print('Biometric authentication failed');
  },
)

Note: For biometric features to work, you need to add local_auth to your pubspec.yaml:

dependencies:
  local_auth: ^2.0.0

Example with Security Features #

PinPlusKeyBoardPackage(
  pinInputController: _pinController,
  spacing: 40,
  onSubmit: () {
    // Handle PIN submission
  },
  // Auto-clear PIN after 30 seconds of inactivity
  autoClearTimeout: Duration(seconds: 30),
  // Enable screenshot blocking (Android only)
  enableScreenshotBlocking: true,
  // Rate limiting
  maxFailedAttempts: 5,
  rateLimitWindow: Duration(minutes: 15),
)

Example with Random Keyboard Layout #

The random keyboard feature shuffles the positions of numbers 1-9 on the keyboard, making it harder for observers to see which numbers are being pressed (shoulder surfing protection). The zero button always remains in the center position.

PinPlusKeyBoardPackage(
  pinInputController: _pinController,
  spacing: 40,
  onSubmit: () {
    // Handle PIN submission
  },
  // Enable random keyboard layout
  enableRandomKeyboard: true,
  // Reshuffle when PIN is cleared (optional)
  reshuffleOnClear: true,
  // Reshuffle when app comes to foreground (optional)
  reshuffleOnResume: true,
)

Security Benefits:

Shoulder Surfing Protection: Random number positions make it difficult for observers to determine which numbers are being pressed
Enhanced Privacy: Even if someone watches you enter your PIN, they can't easily replicate it on a standard keyboard layout
Flexible Reshuffling: Choose when to reshuffle - on initialization, on clear, or when app resumes

Note: The random layout only affects numbers 1-9. The zero button (0) always remains in the center position of the bottom row for consistency.

Example with Theme Presets #

import 'package:pin_plus_keyboard/pin_plus_keyboard.dart';

// Use iOS-style preset
PinPlusKeyBoardPackage(
  pinInputController: _pinController,
  spacing: 40,
  onSubmit: () {},
  ...PinThemePresets.iosStyle(),
)

// Use Material 3 preset
PinPlusKeyBoardPackage(
  pinInputController: _pinController,
  spacing: 40,
  onSubmit: () {},
  ...PinThemePresets.material3Style(
    colorScheme: Theme.of(context).colorScheme,
  ),
)

Example with Hidden Input (Password Style) #

PinPlusKeyBoardPackage(
  pinInputController: _pinController,
  spacing: 40,
  onSubmit: () {
    // Handle PIN submission
  },
  isInputHidden: true, // Hide the input as user types
  inputHiddenColor: Colors.black, // Color to hide the input
)

Example with Dash Style Input #

PinPlusKeyBoardPackage(
  pinInputController: _pinController,
  spacing: 40,
  onSubmit: () {
    // Handle PIN submission
  },
  inputType: InputType.dash, // Underline style instead of box
  inputBorderColor: Colors.blue,
)

Example with Haptic Feedback and Validation #

PinPlusKeyBoardPackage(
  pinInputController: _pinController,
  spacing: 40,
  onSubmit: () {
    // Handle PIN submission
    print('PIN submitted: ${_pinController.text}');
  },
  // Enable haptic feedback for better user experience
  enableHapticFeedback: true,
  // Custom validation - return error message if invalid
  validator: (String pin) {
    // Example: Prevent PINs with all same digits
    if (pin.split('').every((digit) => digit == pin[0])) {
      return 'PIN cannot be all the same digit';
    }
    // Example: Prevent sequential PINs
    if (pin == '123456' || pin == '654321') {
      return 'PIN cannot be sequential';
    }
    return ''; // Empty string means validation passed
  },
  // Track each digit entry (useful for analytics)
  onDigitEntered: (String digit, int position) {
    print('Digit $digit entered at position $position');
  },
)

Example: Clearing PIN Input #

To clear the PIN input (e.g., after validation error or successful submission), use the clear() method on the controller:

// ❌ INCORRECT - This will NOT work:
// pinInputController.text = '';  // Don't do this!

// ✅ CORRECT - Use the clear() method:
pinInputController.clear();

// Alternative - Use changeText() with empty string:
// pinInputController.changeText('');

Complete example with error handling:

class PinEntryScreen extends StatefulWidget {
  const PinEntryScreen({super.key});

  @override
  State<PinEntryScreen> createState() => _PinEntryScreenState();
}

class _PinEntryScreenState extends State<PinEntryScreen> {
  final PinInputController _pinController = PinInputController(length: 6);

  void _handlePinSubmission() {
    // Validate PIN (e.g., check with backend)
    if (_isValidPin(_pinController.text)) {
      // Success - clear PIN and navigate
      _pinController.clear();
      Navigator.push(context, MaterialPageRoute(builder: (_) => HomeScreen()));
    } else {
      // Error - show error message and clear PIN
      ScaffoldMessenger.of(context).showSnackBar(
        const SnackBar(content: Text('Invalid PIN. Please try again.')),
      );
      // Clear the PIN input so user can try again
      _pinController.clear();
    }
  }

  bool _isValidPin(String pin) {
    // Your validation logic here
    return pin == '123456'; // Example
  }

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      body: PinPlusKeyBoardPackage(
        pinInputController: _pinController,
        spacing: 40,
        onSubmit: _handlePinSubmission,
        validator: (String pin) {
          if (pin.length < 6) {
            return 'PIN must be 6 digits';
          }
          return ''; // No error
        },
      ),
    );
  }

  @override
  void dispose() {
    _pinController.dispose();
    super.dispose();
  }
}

Important Notes:

Always use pinInputController.clear() to clear the PIN input
Do NOT directly assign to pinInputController.text as it won't trigger UI updates
The clear() method automatically notifies all listeners and resets animations
After clearing, the input fields will be empty and ready for new input

Example with Gradients #

PinPlusKeyBoardPackage(
  pinInputController: _pinController,
  spacing: 40,
  onSubmit: () {
    // Handle PIN submission
  },
  // Gradient for keyboard buttons
  buttonGradient: LinearGradient(
    colors: [Colors.blue, Colors.purple],
    begin: Alignment.topLeft,
    end: Alignment.bottomRight,
  ),
  // Gradient for input fields
  inputGradient: LinearGradient(
    colors: [Colors.grey.shade100, Colors.grey.shade200],
  ),
)

Example with Custom Builders #

PinPlusKeyBoardPackage(
  pinInputController: _pinController,
  spacing: 40,
  onSubmit: () {
    // Handle PIN submission
  },
  // Custom input field builder
  inputFieldBuilder: (context, position, hasCharacter, character) {
    return Container(
      // Your custom input field design
      child: Text(character ?? ''),
    );
  },
  // Custom keyboard button builder
  keyboardButtonBuilder: (context, number) {
    return ElevatedButton(
      onPressed: () {
        // Handle button press
      },
      child: Text(number),
    );
  },
)

Accessibility #

The package includes comprehensive accessibility support:

Screen Reader Support: All interactive elements have semantic labels
Keyboard Navigation: Users can navigate using keyboard arrows (when enabled)
High Contrast Mode: Automatically adapts to system accessibility settings
Semantic Labels: Proper labels for all buttons and inputs

PinPlusKeyBoardPackage(
  pinInputController: _pinController,
  spacing: 40,
  onSubmit: () {},
  // Custom semantic label
  semanticLabel: 'Enter your 6-digit PIN code',
  // Enable keyboard navigation
  enableKeyboardNavigation: true,
)

API Reference #

PinInputController #

The controller manages the state of the PIN input.

Properties

length (int): The number of input fields (required)
text (String): The current PIN value

Methods

changeText(String text): Updates the PIN value and notifies all listeners
clear(): Clears the PIN value and notifies all listeners. This is the recommended way to clear the PIN input.
addListener(VoidCallback listener): Listen to changes
removeListener(VoidCallback listener): Remove listener

Important: Do not directly assign to the text property. Always use clear() or changeText() methods to ensure the UI updates correctly.

Getters

isComplete (bool): Returns true if all fields are filled
isEmpty (bool): Returns true if no input has been entered
