modeless_drawer 0.0.3

A modeless dialog for updating displayed values without closing the drawer

modeless_drawer

This package provides a modeless dialog that can be displayed on top of the stack. By positioning it at the top of the stack, it achieves a modeless dialog that appears at the right edge of the screen. The modeless dialog supports manual and programmatic opening and closing of the drawer, as well as updating the values displayed within the dialog.

Motivation

In Flutter, there are several types of drawers, including the native drawer and many customized drawers. Typically, the fundamental behavior of a drawer is to close when the user taps outside of it. However, in applications like Figma, where users need to view properties of selected items, the content within the drawer updates with each selection. Closing and reopening the drawer every time a new item is selected is inefficient and negatively impacts the user interface and experience.

Recognizing this inefficiency and the absence of an appropriate solution, ModelessDrawer was developed. This drawer has two main features:

1. Modeless Behavior: The drawer does not close when tapping outside of it, allowing for uninterrupted workflow.
2. Dynamic Content Update: The drawer content updates based on the selected widget's data, providing a seamless user experience.

These features address the need for a more efficient and user-friendly drawer in scenarios where frequent updates to the drawer content are necessary.

Screenshot

Usage

Here are small examples that show you how to use the API.

Install

import 'package:modeless_drawer/modeless_drawer.dart';

Setting the GlobalKey

First, set a GlobalKey for the ModelessDrawer to control its state. This key is necessary for programmatically opening, closing, and updating the drawer.

final _kerDrawer = GlobalKey<ModelessDrawerState<CountryInfo>>();

Placing the Drawer Behind the Stack

Place the ModelessDrawer at the top of the stack, so it appears above the rest of the content.

return Stack(
  children: [
    Scaffold(
      appBar: AppBar(
        title: Text(widget.title),
      ),
      // Your other content here
    ),
    ModelessDrawer<CountryInfo>(
      key: _kerDrawer,
      builder: (BuildContext context, CountryInfo? country) => ...
    ),
  ],
);

Opening the Drawer

To open the ModelessDrawer, call the open() method on its state using the GlobalKey.

_kerDrawer.currentState?.open();

Closing the Drawer

To close the ModelessDrawer, call the close() method on its state using the GlobalKey.

_kerDrawer.currentState?.close();

Passing Data to the Drawer

To pass data to the ModelessDrawer, use the changeValue() method on its state. This updates the drawer's content with the provided data.

_kerDrawer.currentState?.changeValue(country);

Setting the Drawer Content

The content of the ModelessDrawer is set using the builder parameter. This parameter takes a function that returns a widget based on the passed data.

ModelessDrawer<CountryInfo>(
  key: _kerDrawer,
  builder: (BuildContext context, CountryInfo? country) =>
      country == null
          ? const Text('Not selected')
          : Column(
              mainAxisAlignment: MainAxisAlignment.center,
              children: [
                Text(
                  toFlag(country.code),
                  style: const TextStyle(fontSize: 64),
                ),
                Text(country.name),
                Text('Capital: ${country.capital}'),
              ],
            ),
)

Showing/ Hiding the Drawer When Closed

To show or hide the drawer when it is closed, use the widthWhenClose parameter. If widthWhenClose is set to 0 (default), the drawer will be hidden when closed.

ModelessDrawer<CountryInfo>(
  widthWhenClose: _showWhenClosed ? 32 : 0,
)

Minimum Example

For more comprehensive use cases utilizing data classes, please refer to the Example section.

import 'package:flutter/material.dart';
import 'package:modeless_drawer/modeless_drawer.dart';

void main() {
  runApp(const MyApp());
}

class MyApp extends StatelessWidget {
  const MyApp({super.key});

  @override
  Widget build(BuildContext context) {
    return MaterialApp(
      title: 'Flutter Demo',
      theme: ThemeData(),
      home: const MyHomePage(title: 'ModelessDrawer Demo'),
    );
  }
}

class MyHomePage extends StatefulWidget {
  const MyHomePage({super.key, required this.title});

  final String title;

  @override
  State<MyHomePage> createState() => _MyHomePageState();
}

class _MyHomePageState extends State<MyHomePage> {
  final _kerDrawer = GlobalKey<ModelessDrawerState<String>>();

  @override
  Widget build(BuildContext context) {
    return Stack(
      children: [
        Scaffold(
          appBar: AppBar(
            title: Text(widget.title),
          ),
          body: Column(
            mainAxisAlignment: MainAxisAlignment.center,
            crossAxisAlignment: CrossAxisAlignment.start,
            children: [
              for (final value in ['One', 'Two', 'Three'])
                TextButton(
                  onPressed: () {
                    _kerDrawer.currentState?.changeValue(value);
                    _kerDrawer.currentState?.open();
                  },
                  child: Text(
                    value,
                    style: const TextStyle(fontSize: 32),
                  ),
                ),
            ],
          ),
        ),
        ModelessDrawer<String>(
            key: _kerDrawer,
            builder: (BuildContext context, String? selectedValue) =>
                Text(selectedValue ?? 'Not selected')),
      ],
    );
  }
}

Contributing

Pull requests are welcome. For major changes, please open an issue first to discuss what you would like to change.

Please make sure to update tests as appropriate.

License

This project is licensed under the MIT License.
