Flutter Robot 🤖📱

Create widget tests using the Robot Pattern!

This package provides a good approach to create tests for your pages by validating the correct interaction between controller and widget. This way you can verify if your view shows/behaves exactly as expected for each controller state (cubit/bloc/mobx/etc).

Progress	Feature
✅	Simulate multi device screen sizes
✅	Simulate home IOS button
✅	Simulate status bar
✅	Simulate keyboard open

Installation

Add it to your pubspec.yaml as a dev_dependency:

dart pub add dev:flutter_robot

Creating your first Robot test

To implement the Robot Pattern, you'll need to create 2-3 files:

{page_name}_robot.dart - Contains the robot implementation
{page_name}_test.dart - Contains the actual tests
{page_name}_scenarios.dart - (Optional) Used when you need to mock multiple scenarios

Typical folder structure:

my_project/
└── lib/
└── test/
    └── feature/
        ├── feature_robot.dart
        ├── feature_scenarios.dart
        └── feature_test.dart

First step - Creating a robot

In this first example, we will not use scenarios. So, we set a fixed scenario to 'RobotScenario.none()'.

my_feature_page_robot.dart


class MyFeaturePageRobot extends Robot {
  DevicesRobot({
    required super.tester,
  });

  @override
  Widget build() {
    // return here your widget/page to test
    return const MyFeaturePage();
  }

  Future<void> assertScreen() {
    return takeSnapshot('MyFeaturePage_screen');
  }

  // Create here others methods to interact with 'WidgetTester' API like a `tap`, `enterText`, etc.
  // Or use RobotElement to find a widget and interact with it.

}

Second step - Creating a test

my_feature_page_test.dart


import 'package:flutter_robot/flutter_robot.dart';
import 'package:flutter_test/flutter_test.dart';

import 'my_feature_page_robot.dart';

void main() {

  setUpRobot(
    (tester) => MyFeaturePageRobot(tester: tester),
  );

  testRobot<MyFeaturePageRobot>(
    'Should show page correctly',
    (robot) async {
      await robot.assertScreen();
    },
  );
}

Creating a golden files

Now just run the command flutter test --update-goldens. If everything is ok, your test will pass and create a folder named golden_files and inside that the file MyFeaturePage_screen.png.

Ready! When you run flutter test your test will validate the golden test.

Creating test using scenarios

First of all, what are scenarios here? Scenarios are a group of mocks that help you to arrive in a specific state of your controller to validate it.

In this kind of test, we don't mock the controller, we mock the controller dependencies.

The idea here is testing the controller and the view.

So, let's keep going!

The first step is to create a scenarios file. Just create a class and extend RobotScenario:

example_page_scenarios.dart


abstract class ExamplePageScenarios extends RobotScenario{
  @override
  FutureOr<void> injectDependencies() {}

  @override
  FutureOr<void> mockScenario() {}

}

We are not going to do anything here at the moment. But you already know that in the injectDependencies method you will insert the code to inject the page dependencies and in the mockScenario method you will insert the code to mock the dependencies.

After that, let's implement the base of your robot file.

example_page_robot.dart


class ExamplePageRobot extends Robot<ExamplePageScenarios> {
  ExamplePageRobot({
    required super.tester,
  });

  @override
  Widget build() {
    return const ExamplePage();
  }
}

Great, you have the base! Now just add your interactions and validations.

Let's create a test with golden validation for the success scenario:

Create a success scenario in example_page_scenarios.dart:


class GetExampleInfoUsecaseMock extends Mock implements GetExampleInfoUsecase {}

abstract class ExamplePageScenarios extends RobotScenario {
  late GetExampleInfoUsecase usecase;
  late ExampleCubit cubit;

  ExamplePageScenarios() {
    usecase = GetExampleInfoUsecaseMock();
    cubit = ExampleCubit(usecase: usecase);
  }

  @override
  FutureOr<void> injectDependencies() {
    serviceLocator.registerFactory(() => cubit);
  }

  @override
  FutureOr<void> mockScenario() {}
}

class ExamplePageSuccess extends ExamplePageScenarios {
  @override
  FutureOr<void> mockScenario() async {
    await super.mockScenario();
    when(() => usecase.call()).thenAnswer((_) async => 'Example Info');
  }
}

Create a method to validate the golden files in your 'Robot' file.


class ExamplePageRobot extends Robot<ExamplePageScenarios> {
  ExamplePageRobot({
    required super.tester,
  });

  @override
  Widget build() {
    return const ExamplePage();
  }

  Future<void> assertSuccessScreenGolden(){
    return takeSnapshot('ExamplePage_success');
  }
}

If you are providing the cubit by provider you can wrap the widget with BlocProvider in the build method:


  @override
  Widget build() {
    return BlocProvider(
      create: (context) => scenario.cubit,
      child: const ExamplePage(),
    );
  }

Create a test

example_page_test.dart


import 'package:flutter_test/flutter_test.dart';

import 'example_page_robot.dart';
import 'example_page_scenarios.dart';

void main() {

  setUpRobot(
    (tester) => ExamplePageRobot(
      tester: tester,
    ),
  );

  testRobot<ExamplePageRobot>(
    'Should show the success case correctly',
    (robot) async {
      await robot.assertSuccessScreenGolden();
    },
    scenario: ExamplePageSuccess(),
  );
}

That is it. Now just run the command to create the golden files if you are using the golden test.

Running test in multi devices

To run your Robot test in multiple devices simulating statusBar, Keyboard opened, or ios home button you can pass the devices param in the testRobot method.


void main() {

  setUpRobot(
    (tester) => ExamplePageRobot(
      tester: tester,
    ),
  );

  testRobot<ExamplePageRobot>(
    'Should run in all devices',
    (robot) async {
      await robot.assertScreen();
    },
    devices: [
        RobotDevice.small(),
        RobotDevice.medium(),
        RobotDevice.large(),
        RobotDevice(
          name: 'custom',
          sizeScreen: const Size(800, 800),
          withStatusBar: true,
          withKeyboard: true,
          withIOSHomeButton: true,
        ),
      ],
  );
}

Using RobotElement

The RobotElement is a class that helps you to find a widget in the widget tree and interact with it.

Here's an example of how to use RobotElement in your tests:

class MyFeaturePageRobot extends Robot {
  MyFeaturePageRobot({
    required super.tester,
  });

  @override
  Widget build() {
    return const MyFeaturePage();
  }

  // Get a specific element by key
  RobotElement get submitButton => RobotElement.byKey(Key('submit_button'), tester);

  // Get an element by type
  RobotElement get textField => RobotElement.byType(TextField, tester);

  // Get an element by text
  RobotElement get welcomeText => RobotElement.byText('Welcome!', tester);

  // Get an element by icon
  RobotElement get settingsIcon => RobotElement.byIcon(Icons.settings, tester);

}

Using in test:

void main() {
  setUpRobot(
    (tester) => MyFeaturePageRobot(tester: tester),
  );

  testRobot<MyFeaturePageRobot>(
    'Should interact with the elements',
    (robot) async {
      await robot.submitButton.scrollTo();
      await robot.submitButton.tap();
      await robot.welcomeText.assertIsVisible();
      await robot.settingsIcon.longPress();
      await robot.textField.enterText('Test input');
    },
  );
}

Loading fonts

To load fonts to show the text and icons in your golden files you can use the RobotFontLoaderManager. By default, the robot will load the material icons and the fonts defined in your pubspec.yml. (MaterialIconsFontLoader and PubspecFontLoader)

If you need to load a font different from the default you can create a custom RobotFontLoader and add it to the RobotFontLoaderManager. Like this:


import 'package:flutter_robot/flutter_robot.dart';

class MyCustomIconFontLoader extends RobotFontLoader{

  @override
  Future<void> load() async {
    // Load here your font
  }
}

Create a file in your test folder named flutter_test_config.dart.


import 'dart:async';

import 'package:flutter_robot/flutter_robot.dart';

Future<void> testExecutable(FutureOr<void> Function() testMain) async {
  RobotFontLoaderManager().add(MyCustomIconFontLoader());
  return testMain();
}

Or just override the method fontLoaders in your Robot class.


import 'dart:async';

import 'package:flutter_robot/flutter_robot.dart';

class MyRobot extends Robot {

  List<RobotFontLoader> get fontLoaders => [
    MyCustomIconFontLoader(),
  ];

}

Loading Assets

The robot will try to load all ImageProviders present in the widget tree.

If you need to load an asset different from ImageProvider you can override the method onLoadAssets and do it there using loadImageProvider.

To load assets manually during the test you can call loadAsyncImageProvider;

Golden diff threshold

It is common to work in an OS different from CI. In these cases, tests could fail due to slight pixel differences in your golden test when running in CI.

To try to avoid these failures you could set a threshold. The threshold default is 1%, that is, if the golden test fails with 0.5% of diff your test will pass.

To change this default value you can set it in RobotFileComparator.

Using the file flutter_test_config.dart:


import 'dart:async';

import 'package:flutter_robot/flutter_robot.dart';

Future<void> testExecutable(FutureOr<void> Function() testMain) async {
  RobotFileComparator.thresholdDefault = 0.05; // 5%
  return testMain();
}

You also can set a specific threshold to a Robot, just pass the param goldenThreshold in your super. This way just in this Robot test will use this threshold:


class ExamplePageRobot extends Robot {
  ExamplePageRobot({
    required super.tester,
    required super.scenario,
  }):super(goldenThreshold:0.05);

  ...
}

If necessary you can customize the functions compare, update, or getTestUri of RobotFileComparator.
